Quadral Platinum
Data[edit]
General
- Manufacturer: Quadral
- Model: Platin
- Years of manufacture: 1993
- Made in: Germany
- Color: black, agate gray
- Dimensions: 800 x 220 x 288 mm (H x W x D)
- Weight: 12,5 kg
- Original price: 1200 DM
Technical Data
- Type: 3-way bass reflex, floorstanding speaker
- drivers:
- woofer: 2x 170 mm, 92 1053 with 3.5 Ohm and 92 1054 with 7 Ohm
- tweeter: 1x 25 mm dome tweeter, 92 3020 with 6 Ohm
- power handling (nominal / music): 100 / 180 Watt
- efficiency: 89.5 dB/1W/1m
- frequency response: 30 Hz - 22,000 Hz
- Transitional ranges: 250 / 3,000 Hz
- Impedance: 4 Ohm
Remarks[edit]
Item no. 180030
Other models in the same series:
Successor model:
