Latest revision as of 12:04, 28 October 2025
Data
General
- Manufacturer: Quadral
- Model: Wotan Mk III
- Years of manufacture: 1986 - 1990
- Manufactured in: Hanover, West Germany
- Colour: antique walnut, mahogany, rustic oak, black oak, natural oak; special requests possible
- Dimensions: 720 x 380 x 350 mm (H x W x D)
- Weight: 32,5 kg
- Original price approx.: 1.598,- DM/piece
Technical Data
- Type: 3-way, O.L.C.D, floorstanding speaker
- Chassis:
- Woofer: 1x 260 mm (W 250/50/9/PF/AA).
- Midrange driver: 1x 132 mm
- Tweeter: 1x ribbon tweeter
- power handling (nominal/music): 150 / 200 W
- Efficiency: ? dB/1W/1m
- Frequency response: 30 - 50.000 Hz
- crossover frequency: 280 / 4.000 Hz
- Impedance: 8 Ohm
Special Features
Remarks
Article no.: without imprint Other models of the same series (in ascending order of size):
Previous models
Successor models:
Pictures
- Extract from brochure: Quadral palette 1987
