Wharfedale Diamond 11.4

Data

General

• Manufacturer: Wharfedale
• Model: Diamond 11.4
• Years of manufacture: 2016 - ?
• Made in: Designed and engineered in the United Kingdom
• Colour: Black and White currently Rosewood and Walnut tbc
• Dimensions (W x H x D): 985x222x320mm
• Cabinet volume: Mid 12L; Bass 30.9L
• Weight: 24 kg
• Original price approx.: €999

Technical data

• Type: 3-way floorstander, Bass reflex (slot loaded)
• Chassis:
  • Bass: 2x 150mm woven Kevlar
  • Midrange: 100mm woven Kevlar
  • Tweeter: 25mm textile dome
• recommended Amplifier power: 25-175 W
• Power handling (nominal/music):
• Efficiency:
• Frequency Response: 42Hz-20kHz
• Transient response: (for LS with multiple drivers).
• Impedance: 8 Ohms compatible
• Sensitivity: 91dB
• crossover frequency:

Special Features

Remarks

Where the 11.3 is really a 2½ way speaker, the 11.4 is a genuine 4 driver 3 way with 2 x 150mm bass drivers and 100mm mid to add to the 25mm tweeter. It handles up to 175W of power and has high sensitivity and wide frequency response to deliver incredible detail as well as huge punch.
